| Product Name | ASTM A709 Carbon Steel Plate |
|---|---|
| Production Process | Hot Rolling, Cold Rolling |
| Material Standards | AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE |
| Width | 100mm – 3000mm |
| Length | 1m – 12m or Customized |
| Thickness | 0.1mm – 400mm |
| Delivery Condition | Rolling, Annealing, Quenching, Tempered |
| Surface Process | Ordinary, Wire Drawing, Laminated Film |
| Thickness | C (%) | Si (%) | Mn (%) | P (%) | S (%) |
|---|---|---|---|---|---|
| < 12.5mm | 0.27 | 0.13–0.45 | 0.79–1.30 | 0.035 | 0.035 |
| 12.5–50mm | 0.28 | 0.13–0.45 | 0.79–1.30 | 0.035 | 0.035 |
| 50–100mm | 0.30 | 0.13–0.45 | 0.79–1.30 | 0.035 | 0.035 |
| 100–200mm | 0.31 | 0.13–0.45 | 0.79–1.30 | 0.035 | 0.035 |
| > 200mm | 0.31 | 0.13–0.45 | 0.79–1.30 | 0.035 | 0.035 |
| Thickness (mm) | Yield Strength (MPa) | Tensile Strength (MPa) | Elongation (%) |
|---|---|---|---|
| 6–50 | ≥260 | 485–620 | 21 |
| 50–200 | ≥260 | 485–620 | 17 |
| Density (Metric) | 7.80 g/cc |
|---|---|
| Density (Imperial) | 0.282 lb/in³ |
We continuously improve product quality and service levels, providing customers with higher-quality and more efficient metal product solutions.
